Viton Rubber Sheet

Advanced Seals & Gaskets produce high-quality sheets using a diverse range of material types, some of which are designed for unique industries and applications, one such material is Viton rubber sheets, which is specially made to resist extreme temperatures and harsh chemicals.

Viton rubber is manufactured in roll form with thicknesses starting at 0.5mm, which ASG can convert into various other products including sheets, supplied with a plain or self-adhesive finish using our in-house laminating service.

Viton rubber is often taken in roll or sheet form as they give the customers and end-users the flexibility to cover larger surface areas and to be able to cut their own strips/gaskets/washers/pads out as and when they are required.  Viton rubber sheets can be produced in different grades each with different levels of resistance, produced for use in different applications and environments.

What are Viton Rubber Sheets?

Viton rubber is fluoroelastomer, a synthetic rubber that is fluorocarbon-based developed for high temperature and chemical resistance.  Viton rubber sheets can be purchased in pre-cut sizes, or as full rolls of material, in thicknesses starting from just 0.5mm. Rolls are sometimes preferred by customers as they have the freedom to cut their own sheets in various sizes as and when they are required.  Viton rubber sheets can be supplied with a choice of finishes including foils, self-adhesives or laminated with other materials.

Viton Rubber Sheet

Product Enquiry

For information on Viton Rubber Sheet please complete the following quick enquiry or call us on +44(0)1384 252555.






    Product Specification & Key Characteristics

    • Colour: Black (blue or white in FDA grades)
    • Temperature Range:
      • -20ºc to +275ºc (type A)
      • -30°C up to +300°C (type B)
    • Thickness:  0.5mm - 50mm .
    • Shore Hardness:
      • 75° ± 5° (type A)
      • 70° ± 5° (type B)

    Full technical data can be supplied upon request,
    or downloaded from our online portal.

    Help and guidance

    If you would like to speak to a representative to discuss your specific application or requirements please call our sales office direct on 01384 469100, alternatively you can send an E-mail. Simply click on the link and forward us your details along with your question and we will contact you immediately.

    Samples - Technical Viton Rubber Sheet

    Samples can be submitted for testing upon request.

    Call now for sample requests or further help.

    Sheets

    ASG supply sheets in a wide array of materials such as EPDM, neoprene, rubber, plastic, polyethylene, polyether and polyurethane and many more. We cut our sheets in house using our state of the art machinery, allowing us to work closely with our customers to provide sheets in the desired specifications such as width, thickness and length. Get in touch for more information on our range of sheeting.

    Why use Viton Rubber Sheets?

    There are many reasons to use Viton rubber sheets and it is often a go-to material for applications requiring a high-performance product to meet the demands that cannot be achieved using other polymers such as EPDM or Neoprene.

    Viton rubber sheets and products produced from Viton rubber can withstand extreme temperatures ranging from -20° to 275°C and can maintain their physical and mechanical properties without breaking down even when used with water, acids, petrol, chemicals and oil due to it’s excellent resistance to these.

    Viton rubber sheets are a popular choice of material for use with the automotive, aerospace, oil and gas, and chemical industries - an FDA approved grade is also available for food and drink processing industries.

    Different Grades

    Advanced Seals & Gaskets work with a network of material suppliers and manufacturers, meaning we can offer Viton rubber in additional grades, the most popular of which are detailed below:

    Viton Rubber-Type B - has very similar properties and resistances to Type A, but has a greater fluorine content, which gives it better resistance to fluids and sulfur dioxide, better flexibility after heat exposure and a temperature range of -30°C up to +300°C. Type B is generally used in the most demanding applications and industries such as chemical and power generation.

    Viton FDA grades are available in blue or white options.  This grade is suitable for use for food or pharmaceutical production even at high temperatures.  FDA grade Viton rubber is extremely resistant to animal fats, oils, acids, chemicals and petroleum.

    For more information on the above or other available grades of Viton rubber, please give our sales team a call.

    Benefits of Viton Rubber Sheets

    • Environmental resistance (Ozone, weathering, UV)
    • High Chemical Resistance
    • Weather Resistant
    • Wide Temperature Range
    • Resistance to acid, oil and petroleum-based fluids
    • Withstand Challenging Environments

    Advantages of Using Viton Rubber Sheets

    There are many advantages to using Viton rubber sheets as the material is high performance, versatile and durable, able to withstand high temperatures, is oil and chemical resistant ( even at high temperatures) and will not degrade as easily as other elastomers over time when in contact with chemicals and fluids such as oil, acids, ozone or UV.

    Other grades of Viton rubber are available to order for use in a range of specific industries, details of which can be made available upon request.  Viton rubber sheets are available in a range of standard thicknesses and can be used to convert into a number of other products such as gaskets, strips, rolls, washers and many more.
